ME50 Metal Shaft Magnetic Incremental Encoder

ME50 Metal Shaft Magnetic Incremental Encoder

  • Series：
  • Format：See the following profile
    • Specifications　　

    Encoder model: ME50 series
    name:

    ME50 Metal Shaft Magnetic Incremental Encoder
    Main specifications:

    Dimensions: φ50 X 60mm
    Operating Voltage: 4.5～5.5VDC
    Resolution: 100 pulses/360°
    output signal: A、B、A(一)、B(一
    Features：

    High quality double ball bearings;

    Long life with stable signal;
    Application field： Forklift electric steering wheel, etc.
    ME50 Product Specification

    ONE、MECHANICAL CHARACTERISTIC
    1. Starting torque: 1mN.m
    2. Inertia torque: 1x10-6/ kg.m2
    3. Maximum speed: 6000r/min
    4. Shaft loading: 60N Max (radial direction); 40N Max (axial direction)
    5. Protection level: IP54

    TWO、ELECTRICAL CHARACTERISTIC
    1. Working voltage: DC 4.5-5.5V
    2. Input current: 30 mA Max
    3. Total current: ＜50mA

    4. Output signal: A、B、A(一)、B(一

    5. Output voltage: VOH＞0.7VDD, VOL＜0.5V
    6. Pulses: 100 pulses

    7. Respond frequency: 10MHz

    Note: In this catalog, if some parameters or drawings are different from the "Approval sheet", it's subject to the "Approval sheet".

    download ME50.pdf
